High Grade For Celebrations Indoor Led Full Color Display - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

pitch indoor P1.875

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

1.875mm

Screen Dimension:

Customized Size

Name:

indoor led full color display for kids

Other name:

smd led

Color:

Full-color

Pixel pitch:

1.875mm

Module size:

240mm*240mm

LED chip:

Epistar

Application:

Square, Adervertising, Bank, Hall, Rent

Life span:

100000hours

Certificate:

CE ROHS FCC CCC

Warranty:

2 Years

Packaging & Delivery

Packaging Details:

indoor led full color display for kids packing: Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

High Grade For Celebrations indoor led full color display for kids

Product Description Specification of indoor led full color display for kids

No.

specs HIGH-MINI-PITCH HD Indoor full color PH1.875

1 Pixel structure 1R1G1B 3in1, 1010

2 Pixel pitch 1.875mm 3 Pixel density 284444dots/Sq.

m.

4 Luminance ≥800cd/Sq.

m.

5 Module dimension 240mm(W) * 240mm(H)

6 Module resolution 128 pixel(W) *128 pixelmm(H)

7 Module weight 160g

8 Cabinet dimension 480 * 480mm or other

9 Cabinet area 0.23 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 1.875m

12 Visual angel 140 degree (H/V)

13 Max power consumption 600w /Sq.

m.

14 Average power consumption 300w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/32 dynamic scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
