Ms Sb200 12 - China

Nominal Voltage (V) 12V Rated Capacity: 20hour rate (10.2A 10.80V) 204AH 10hour rate (20.0A 10.50V) 200AH 5hour rate (34.0A 10.20V) 170AH 1 hour rate (122A to 9.6V) 122AH Weight: 60kg Internal Resistance (at 1 KHz) 6mΩ Maximum Discharge Current for 5 seconds: 1000.0A Charging Methods at 25℃ (77℉) Average charging voltage: Charging Voltage 14.1to14.3V Maximum Charging Current 60.0A Standby use: 14.1to14.3V

Float Charging Voltage 13.5to13.8V No current limit required Discharge Current VS.

Discharge Voltage Final Discharge Voltage(V) 10.5V Discharge current(A) (A)≤200 (

A)≥200 Life expectancy:

Cycle Use: 100%

depth discharge 350cycles 50% depth discharge 700cycles 25% depth discharge 1700cycles Standby Use: 6-8 years Case Material: ABS Terminal: embedded M8 copper core (T8) *The above data are of average values, and can be Dimensions: L522*W240*219( mm) obtained within 3 charge/discharge cycles.

These are Total Height (with terminals) 226(mm) not minimum values

Company Contact:

• Posted By: Macsun Solar Energy Technology Co., Ltd.

• Phone: +8675589816120

• Address: Huafeng Industrial Park, Hengkeng, Guantian Village, Beihuan, , Shenzhen , Guangdong , China

• Email:

• Website: http://www.macsunsolar.com

• Business Description: MACSUN SOLAR is a brand-new PV factory who has built a vertically integrated solar product value chain with an overall annual capacity of approximately 600MW.

  Macsun has plenty of experienced professional team members who have been engaged in the fields of solar photovoltaic product development, production and marketing for many years.

  Furthermore Macsun has established technical research cooperation with couples of colleges and universities as well as research institutes.

  Therefore it enjoys strong technical support, which enables our product technical indexes standing the leading position domestically.

  MACSUN SOLAR owns production lines for solar cell, solar module, solar system and other solar application products.

  Technological innovation is essential to our position as a leading global renewable energy provider.

  Our R&D team focuses on the research and development of next generation PV technologies with a constant commitment to product quality and reliability as well as to cost structure optimization.

  With diversified customers base in the global PV market, Macsun Solar delivers its solar modules and PV solutions worldwide.

  MACSUN SOLAR is committed to be socially and environmentally responsible for global carbon emissions.

  Our success is built on the trust of our mutually beneficial customers and partners.

  We constantly strive to reduce our own impact on the environment, and pursuit new solutions of clean energy to benifit people worldwide.



  Our Products:

  - 300w poly crystalline solar panels

  - ms sb200 12
