X42a S11 5k Bevel Push Rod Limit Switch - China

bevel push rod limit switch

1 - Protection level IP65

2 - Cert: CE, TUV, CCS, RoHS

3 - High repeating accuracy and switching time accura

X42A-S11/5K bevel push rod limit switch

The X42 series limit switch (also called travel switch) is

an automatic control apparatus used to switch the circuit

according to the position of the motion part, by doing which

to control the motion direction, travel size or protection

of the position of the moving part.

It can be divided into

mechanical type and electrical type.

For now, our X42A

series limit switch belongs to the former, which is mainly

composed of switching component, wiring terminal, switch

actuating part and transmission part.

Based on the

mechanical ON/OFF principle of the switch contact head, it

can be divided into two categories:

Slow-action switch: the switching time of the ON/OFF action

is independent of the acting speed of the switch, the faster

the acting speed is, the faster the switching is.

Snap-action switch: the switching time of the ON/OFF action

is dependent on the acting speed of the switch, the ON/OFF

switching is activated as soon as the switch actuating part

reaches the required position.

1 - Rugged and durable, housing of high performance enhanced

flame retardant nylon features superior impact resistance;

2 - The normally closed contact head of the limit switch is

of positive closing type, which is safe and reliable, and

fully conforms to the international safe switch standard;

3 - Easy installation using two screws to attach the switch

to the machine;

4 - 12 types of actuating parts available for the switch,

able to be used in various applications, and all the

operating head is able to rotate 90 degress along the four

directions;

5 - Easy wiring, the cover of the switch box is latch locked

without fastening screws, when wiring only one action is

required to open the cover;

6 - High repeating accuracy and switching time accuracy;

7 - Long life time, 5 million times of the mechanical life

time and 500 thousond times of electrical life time;

8 - IP65 protection.
