Thyristor module:

- Chip electrically insolated from baseboard AC2500V

- Vacuum+sufficient hydrogen protection bonding technique

Phase Control Thyristor Module

Thyristor Module dual SCR Module MTC120- 200A

Product Features

- - Chip electrically insolated from baseboard AC2500V

- - international standard seal

- - Vacuum+sufficient hydrogen protection bonding technique

- - Compression connection structure, fine temperature, The

characteristic and below power circulation ability

- - Modules under 350A either with wind- cooling or water-

cooling

- - The volume is small, the weight is light.

Thyristor Module dual SCR Module MTC120- 200A

Typical Applications

- - AC& DC motor control

- - Various rectifying power supply

- - Industrial heating control

- - Dimming

- - Contactless switch

- - Motor soft start

- - Static reactive compensation

- - Electric welding machine

- - Frequency converter

- - UPS power supply

- - Battery charge and discharge

Module and Circuit Diagram

Technical Parameters

Type mean

value

of

on- state leakvage current reverse

off- state repetitive peak

voltage on- state

peak

voltage

/ current ITMVTM direct and reserse repetitive peak current

IDRMIRRM trigger current IGT trigger voltage

VGT extinction current

mA critical rate of rise of off- state voltage

dv/ dt critical rate of off- state current

di/ dt maximum rated junction temper

- ature

Tjm isolation voltage

Viso

A V V A mA mA V

mA V/ μ s A/ μ s °C V( AC)

MTC30A 30 400- 1800 1.5 80 8 100

2.5 100 800 50 125 2500

MTC60A 55 400- 1800 1.5 80 8 100

MTC70A 70 400- 1800 1.9 170 10 100

MTC90A 90 400- 1800 1.9 270 15 100

2.5 100 800 100 125 2500
