Switch Mode Power Supplies For Detector Mesurement Instruments - China

switch mode power supplies for detector mesurement instruments, 12V3A

Power Adapter , with UL/ CUL, FCC, PSE, CE, GS, CB , BSMI, SAA

certification , ROHS , efficiency level V .

Specification details:

Description

Market: USA, Canada, England, China, Australia, Japan

Desk- top Type

Meet CEC Regulations

ROHS Compliance

Efficiency Level V

General Specifications

Maximum output power: 36W

Input voltage: 90~264Vac

Input Frequency: 47Hz~63Hz

Input Current: 1.2A

Leakage Current ( max) : 0.25mA

No Load Power Consumption: Less than 0.3W

Efficiency: Meet CEC

Ripple noise ( max) : +1% Voltage Max

Line Regulation: ±1%

Load Regulation: ±5%

Hold- Up Time: 16mS

Over Voltage Protection: 120%

Operating Temperature: 0~40°C

Storage Temperature: - 20~85°C

Storage Humidity: 5% RH~95% RH

Withstand voltage: AC 3KV

Burn- In Test: 100% Full Load

MTBF: 50000Hours

Weight: 175g

Dimensions

LxWxH: 96.8x44.8x29.3 ( mm)

Company Contact:

• Posted By: GME Technology Co.,Ltd

• Phone: 8675533651689

• Address: A19,Western Industrial Area,Tantou Village ,Songga, Shenzhen city, China

• Email:

• Website: https://www.chinaadapter.com

• Business Description: GME Technology Co., Ltd is a professional manufacturer of ac/dc

  switching power supply, switching power adapter, led dirver, PSU and

  chargers.

  our products have attained several safety certifications,

  such as PSE (Japan), UL, FCC (USA), GS, CE(Europe), SAA, C TICK

  (Australia), CCC (China), BSMI (Taiwan) and KC (Korea) etc .

  GME focus on maintaining quality and offering perfect after sale service , ISO9001: 2000, ISO14000 and ERP system s application to ensure us to provide safety product with not only superior quality but also competitive price for customer .

  we have the ability to develop ourselves specialties to meet client s diversity demands and ever changing markets.

  GME s overriding aim is to give our user 100% satisfaction with switching power adapters.
