Rf Receiver Chip Cmt2250a 2251a - China

Parameter:

Part Number: CMT2250A | CMT2251A

Frequency: 300~480MHz( Support software settings)

Modulation Mode: OOK

Data Rate: 0.1~40Kbps( Support software settings)

Sensitivity: - 114 dBm( 1kbps 0.1% BER)

Measured Distance: Product: & gt; 300m, Demo Board: & gt; 1000m

Blocking Immunity: SR=1Kbps, & plusmn; 1/ 2/ 10MHz Offset:

52/ 74/ 75db

Power Supply: 1.8~3.6V

Rx Current: 315MHz: 3.5mA; 434MHz: 3.8mA

Duty- Cycle Rx Mode: Support software settings,

Reduce average working current

Receiver Start- up Time: DutyCycle: On 12.3ms/ off 7.3ms

Receiver Wake- up Time: & lt; 1ms

Able to inhibit noise output: Support, It is suitable for

the applications

Where RC scope is to be restricted

Learning mode: Available

Crystal: 26MHz+/ - 20PPM

Program Limes: One million times

Operation Temperature: - 40~+85

Communication Mode: Decode( OUTPUTx4) Decode( 1 PWM)

Chip Package: QFN- 16

IC Size: 3x3x0.75mm

Certifications:

ROHS\ REACH\ CE, Etc.

Application:

LED Light Controller, Wireless Remote Control Switch, Smart

Plug, Etc.

RF Advantages:

A revolutionary single- chip solution in the field of RF

remote control

Parameters flexibly configurable and modifiable with

software, simple and user- friendly operations

High measured sensitivity, narrowband applications, long

communication distance

Easily passing safety Blocking Test, very good immunity

Integrated DutyCycle operating mode, reducing the average

operating current, ultra- low power consumption

With unique function of inhibit noise output, it is able to

be applied in special occasions

Different frequencies can be set with software without

changing the crystal, reducing peripheral components

Decoding function, four- way output control/ one- way PWM
