P10 Outdoor Full Color Led Panel - China

Item Technical Parameters

Pixel Pitch 10mm

Led Arrangement DIP346 1R1G1B

Density of Pixel 10, 000Pixels/㎡

Brightness ≥7000nits

Driving Method Constant Drving 1/4 scan

Optimum Viewing Distance >8m

Optimum Viewing Angle H: 110°V: 50°

Module Size 160x160mm

Module Resolution 16*16Pixels

Cabinet Size 960x960mm

Cabinet Resolution 96x96Pixels

Cabinet Weight 50kg

Power Consumption Maximum: ≤900; Average: ≤400w/m2;

IP Rating Front/Rear IP68/IP65

Refresh Rate >1000Hz(Optional)

MTBF >5000hours

Defective Dot Rate <0.0001

LifeSpan >100, 000hours

Input Voltage 110-240 AC±10% 50-60Hz

Working Temperature/Humidity -30℃ - +50℃/10-90％R H

Storage Temperature/Humidity -40℃ - +60℃/10- 90％RH

Input Signal RF, S-VIDEO, RGBHV, YUV, YC & COMPOSITION, etc

Communication Cat5 Cable(≤120m), Optical Fiber ( >120m)

Operating Platform WINDOWS (WIN98, WIN2000, WIN XP, WIN 7)

Remark: The above parameters are just for your reference.

It can be changed according to customer’s requirements
