Lw34 12 10kv Outdoor Sf6 Circuit Breaker - China
price: contact company for price
LW34-12 10KV outdoor SF6 circuit breaker
Product Description
LW34-12 10KV outdoor high voltage SF6 circuit breaker is a new outdoor high-voltage electrical arcing and SF6 gas as insulating medium.
The operating mechanism points manual storage spring mechanism, motor energy storage spring mechanism, DC electromagnetic actuator three, all kinds of fish breaker actuator perfect combination of body as a whole.
This product compared to other fish 10kV class outdoor circuit breakers, has a simple structure, high arcing and insulation performance, small operating power, high ratings, long life and no maintenance cycle and other significant advantages.
Use of this product will not only reduce the area.
Reduce project cost and eliminate the risk of fire, and can greatly improve the reliability of the power system.
Technical parameter
Rated
voltage
(kV) Rated
current
(A) Rated
short-circuit
breaking current
(kA) Rated
short-circuit
current
(kA) Rated peak
withstand
current
(kA) Rated short
time withstand
current
(KA) Rated short
duration
(S) Rated
short-circuit
current
breaking times Weight
(kg)
10 400
630 6.3
8
12.5 16
20 16
20 6.3
8
12.5 4 30 130
Company Contact:
- Posted By: Bokong Electric Co., Ltd
- Phone: 86-577-62769817
- Address: 191, Wei shiliu Road, Yueqing City Economic Development, Wenzhou , Zhejiang , China
- Email:
- Website: https://www.bokrelec.com
Published date: March 5, 2024
- Business Description: Established in 11/2011, Bokong Electric company is a professional manufacturer and exporter that is concerned with the design, development and production of MV & LV switchgear assemblies & MV components.
We are located in Yueqing city in Zhejiang province, China, with convenient transportation access that It's about 200 KM from Ningbo port and 400 KM from Shanghai port.
(Two largest ports in China.
) All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
Our well-equipped facilities and excellent quality control through all stages of production enables us to guarantee total customer satisfaction.
Besides, we have received the CE certificate and ISO series certificate,meet the requirement of IEC standard.
