Low Price Professional Full Color P3 Led Display - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

project indoor P3

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

Video

Pixels:

64*64

Screen Dimension:

Customized Size

Name:

full color p3 led display

Other name:

Low price full color p3 led display

Brightness:

1200-1500cd/sqm

Certificate:

CE ROHS FCC CCC

Color:

Full-color

Application:

Square, Adervertising, Bank, Hall, Rent

Viewing angle:

140H

Life span:

100000hours

Power Supply:

Chuanglian, Weiye

Pixel pitch:

3mm

Packaging & Delivery

Packaging Details:

full color p3 led display Packing: Carton, wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Low price professional full color p3 led display Product Description

Specification of full color p3 led display

No.

specs Indoor full color PH3

1 Pixel structure 1R1G1B 3in1, 2121

2 Pixel pitch 3mm 3 Pixel density 111111 dots/Sq.

m.

4 Luminance 1000-1200cd/Sq.

m.

5 Module dimension 192mm(W) * 192mm(H)

6 Module resolution 64 pixel(W) *64pixelmm(H)

7 Module weight 330g

8 Cabinet dimension 768 * 768mm or other

9 Cabinet area 0.59 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 3m

12 Visual angel 140 degree (H/V)

13 Max power consumption 780w /Sq.

m.

14 Average power consumption 390w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/32 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
