ISO4021 Series Isolated 0-±100mV, 0-±10V, 4-20mA, 0-±20mA to RS232/RS485 A-D Converter

Model selection：

ISO 4021 U(A)□ - □ U/A: Input voltage or current signal Output: communication interface

U1：0-5V A1：0-1mA 232/485： Output is RS-232 or RS-485 interface

U2：0-10V A2：0-10mA U3：0-75mV A3：0-20mA U4：0-2.5V A4：4-20mA U5：0-±5V A5：0-±1mA U6：0-±10V A6：0-±10mA U7：0-±100mV A7：0-±20mA

U8：Customized A8：Customized Remark：When the communication interface is RS232, it should connect with RXD and TXD port; when the communication interface is RS485, it should connect with DATA+ and DATA- Port.

RS232 and RS485 can’t work at the same time.

E.g.

1： ISO 4021 A4-232/485 Means 4-20ma signal input, output is RS232 or RS485

2： ISO 4021 U1-232/485 Means 0-5V signal input, output is RS232 or RS485

3： ISO 4021 U5-232/485 Means 0-±5V signal input, output is RS485 or RS232 ISO 4021 A-D Converter General Parameters：

(typical @ +25℃, Vs is 24VDC)

Input： Voltage / Current

Accuracy： 0.05%

Input imbalance： ±0.1 uA/℃

Temperature Drift： ±15 ppm/℃ (±30 ppm/℃, max)

Input Resistance： 50Ω (4-20mA/0-20mA/0-±20mA current input) 100Ω (0-10mA/0-±10mA current input) 1KΩ (0-1mA/0-±1mA current input) >1MΩ(voltage input) Band width： -3 dB 10 Hz

Switching rate： 10 Sps

Common mode restraint(CMR)： 120 dB(1kΩ Source Imbalance @ 50/60 Hz)

Normal mode restraint(NMR)： 60 dB (1kΩ Source Imbalance @ 50/60 Hz)

Input Port protection： over-voltage/over current protection

Communications： protocol RS-485 or RS-232 ASCII protocol and MODBUS RTU communication protocol Baud rate(300, 600, 1200, 2400, 4800, 9600, 19200, 38400bps)software configuration

address(00H~FFH)softwa re configuration

Response Time：100 ms max

Operation Power Supply： +8 ~ 50 VDC wide power supply range, internal anti-reverse & over-voltage protection watt consumption： < 1W

Operation Temperature： - 45 ~ +80℃ Operation Humidity： 10 ~ 90% (non-condensing)

Storage Temperature： - 45 ~ +80℃ Storage Humidity： 10 ~ 95% (non-condensing) Isolation withstand voltage： between input and output： 3KVDC, 1 minute, stray current 1mA Output and power are common-ground.

Endure Impact Voltage： 3KVAC, 1.2/50us(peak value)

Dimensions： 83 mm x 37 mm x 51mm

Weight： 72g
