Ingke Ykg 832409nl 100 Percent Cross Xmh 9760 Jl7d130 886 2x4 Ports Rj45 Magjack Connectors - China

Ingke YKG-832409NL 100% cross XMH-9760-JL7D130-886 2x4 Ports RJ45 Magjack Connectors Part Number : XMH-9760-JL7D130-886

Made in China: YKG-832409NL

Original Manufacturer: Ingke Technology

Supply Ability: 5500K-PCS/Month

Product Category: Modular Connectors / Ethernet Connectors

Packaging : Tray

Connector Type: RJ45

Number of Ports : 8

Number of Rows : 2

Applications : 10/100/1000Base-T, AutoMDIX

Mounting Type : Through Hole

Orientation: 90° Angle (Right)

Termination : Solder

LED Color: Green, Yellow-Green, Yellow

Number of Cores per Jack : 8

Shielding : Shielded, EMI Finger

Features: Board Guide

Tab Direction : Up and Down

Contact Material : Copper Alloy

Contact Finish : Gold

Operating Temperature : -40℃~85℃

Flammability Rating: UL 94 V-0

Contact Finish Thickness : 30µin (0.76µm)

Shield Material : Copper Alloy

Housing Material : Thermoplastic Ingke Technology Mass production of the following models;

XMH-9759-B6B2120-136 XMH-G211096 XMH-SK04-G211032BNL XMH-SK04-G211031NL XMH-TRJG28848AHNL XMH-9757-BN32121-136 XMH-TRJG29883AHNL XRJH-04F-5-H6N-1AO XMH-9774-T0I4121-223 XMH-9774-T0I4121-246 XMH-1432C50115 XMH-TRJG47305A47NL XMH-YND69T-036 XMH-04D-E-LB3-1-770-K XMH-592T-10AD-R2B12-C24X XMH-99T1-0340850X23107 XMH-DY9769-T0P4151-074 XMH-SK04-G411032ANL XMH-SK04-G411035ANL XMH-9774-XF94121-006-CX1 XMH-SK04-G4110703NL XMH-04F-5-H6N-SA0 XMH-RJ-G26US-710382A00-R XMH-RJ-G26US-710392B00-R

Company Contact:

• Posted By: Ingke Technology Co.,Ltd

• Phone: 86 (755) 3283-5625

• Address: No.2106,Sanhe Building,Longgang Zone, Shenzhen , Guangdong , China

• Email:

• Website: http://ingketech.net

• Business Description: Ingke Technology specializes in producing 10/100/1000/2.5G/5G/10G Base-T Integrated RJ45 Jacks, since its establishment1993, with technology as dependence and the market as direction, we have developed to be a competitive high-tech enterprise and a leading manufacturer of connectors.

  Partnered with the global leaders in these markets, we continue to develop new products to enable high-speed communication.

  Now we have passed the ISO14001 Environment Management System certification and our parts are all ROHS, CE, UL and SGS parts.

  Our products are widely used in telecommunications, data communications, consumer electronic , computer, industrialand medical markets, such as HUB, SWITCH, IP Phone, Set-Top Box, Smart Home, Embedded System, Networking Camera etc.
