Ebs9b Series Overload Protection Device - China

Product Description

1, The overload protection device breaking capacity: 6kA/10kA

2, Rated current: 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A

3, ISO9001

Product Feature

Function ( EBS9B Mini circuit breakers ):

1 - Can be used in homes, offices, buildings and industries

2 - Overload protection

3 - Short circuit protection

4 - Isolation

5 - Control

Product Specification/Models

Model: EBS9B Mini circuit breaker

Standard: IEC60898

Rated current In (A): 0.5, 1, 2, 3, 4, 6, 10, 16, 20, 25,

32, 40, 50, 63

Rated voltage Ue (V): 230/400

Poles: 1P, 2P, 3P, 4P

Rated insulation voltage Ui (V): 500

Rated impulse withstand voltage (V): 6000

Rated breaking capacity: 6KA/10KA

Rated frequency: 50/60Hz

Trip curve: B, C, D

Thermal operating limit: (1.13~1.45)×In

Energy limiting cass: 3

Mechanical lfe: 20 000

Electrical lfe: 4000

Protection degree: IP20

Mount: on 35mm DIN rail

Other Information

To order EBS9B Miniature circuit breaker, 2 Poles, curve C,

rated current 20A, quantity is 100 pieces, should be marked:

MCB EBS9B/2P C20 100PCS

Payment

L/C D/A T/T D/P

Delivery

Within 25 days

Minimum Order

240 POLES

Packaging

Standard export carton
