Col5300 Standard Alone Scrambler - China

Outline: The COL5300 Standard Alone Scrambler can simulcrypt scramble

the input stream, and the embedded control word generator can transmit

the constant or variable control word to scrambler the input

transmitting stream.

The internal simulcrypt synchronous controller can

transmit the control word and the access conditions to exchange the

information with the ECMG.

When the scrambler works with the CA system,

it can easily help the decoder to correctly decrypt the control word,

and decode the scrambling stream by properly controlling the CP.

Its

high compatibility and integrate design make this device widely being

used in the digital TV scrambling field.

Features • Adopts the general

scrambling system description ETR289 • It can DVB scramble the specific

program or the basic transmitting stream • Complies with the DVB common

scrambling algorithm, supports the simulcrypt mode, be compatible with a

variety of CV systems.

• Analysis the overall MPEG stream • Re-treating

the PSI/SI • Protecting the input and output ASI stream channel •

Supports four different CAS system simultaneously • Supports huge buffer

memory, and resists the unexpected code stream • Supports the bit-rate

self-adoption, the re-adjustment and the re-mark of PCR • Real-time

effective bit-rate monitoring • The database format: 188/244 bytes •

Monitoring the work state by network system • Supports the CAS remote

connection scrambling Specification Input interface Two DVB/ ASl (one

for reserve) Output interface Two DVB/ ASl Output bit-rate 1~54mpbs

Management Ethernet port 10/100M General Dimension 482mm×410mm×45mm

Weight 4kg Work temperature 0~45C(working )，-

20~80C(storage) Power supply AC 110V/220V±10%，50/ 60Hz Power

consumption 11W

Col5300 Standard Alone Scrambler
