J186327 Single Ended Probe - China
price: 0.50 Dollar US$
This probe provides the customer a better in transferring the signal with high frequency.
It is always used made into the inner conductor with stable and low resistance to keep 50Ω impedance.
Mechanical& Electronical Specification
Pitch >3.1mm[ .
122in ]
Working Stroke 2.00mm[.
079in]
Full Stroke 2.40mm[.
094in]
Spring Force 600g at2.00mm[.
094in]
Resistance Max.
10mOhm
Current 3Amp
Operated Temperature -40~125°C
LifeSpan 20, 000 Cycles
Materials
TOP Plunger BeCu/ Au Plated
Bottom Plunger BeCu/ Au Plated
Spring Music Wire/ Au Plated
Tube Bronze/ Au Plated
Company Contact:
- Posted By: JY Electronics Technology Co Ltd
- Phone: 86-(0)21-3769 5886
- Address: No118, Lane 168 South Laiting Road,, Shanghai , China
- Email:
- Website: https://www.jyprobe.com
Published date: October 10, 2019
- Business Description: JianYang is dedicated to the success of our customers by being a world-classical provider of innovative spring contact probe (pogo pin) to the semiconductor test industry and spring contact probe to In-circuit test and Function test factory(OEM ODM).
JianYang, first established in 2008, offers a wide spectrum of spring contact probe (pogo pin), probe pins and services designed to meet the unique challenges of each customer.
As a leading provider of spring contact probe, we at JianYang are committed to delivering value added solutions through our product offerings and expert customer support.
