Gz01 Dc Voltage Multi Parameter Transducer - China

Introduction

This is a DC voltage and current transducer.

The operating principle is Photoelectric Isolation/Treble isolation.

It can measure DC voltage and DC current at the same time, and has two channels of standard signal.

The input, output and power supply are isolated from each other.

It's featured in high accuracy, high isolation, low drift and so on.

This product can be used in railway, industry control, and other fields.

Rated input: 0~1-500V; 0~0.5-5A

Output signal: 0~5V DC (Vz); 0~20mA (Iz); 4~20mA (Iy);0~10V DC (Vd);OC frequency output: (0-5KHz/0-10KHz) optional

Power supply: 12V;15V; 24V; optional

Accuracy: 0.5% optional

Output ripple: 10mV

Isolation: 2500V DC

Humidity: ≤95%(no dew)

Load resistance: Voltage Output >2kohm; Current Output≤250ohm

Temperature drift: 500/ppm℃

Response time: ≤200ms

Operating temperature: : -10℃~+60℃

Quiescent power consumptio: <400mV

Company Contact:

• Posted By: Chongqing Blue Jay Technology Co., Ltd

• Phone: (+0086) 023-67628702

• Address: JingYu Avenue No.153, Building 3A-13-25, Jiangbei District , 400020, Chongqing, P.R.China, chongqing , chongqing , China

• Email:

• Website: https://cqbluejay.com

• Business Description: Application:

  The MCM1000 Series provides a compact and robust metering solution, enable reliable monitoring of building electrical loads with a low installation cost-per-point by combining sub-metering.

  The unit performs real-time metering, measures energy consumption, multitariff time-of-use (TOU) and monitors power quality for max 18 channel circuits for single phase or 6 channel for three phase circuits.

  Advanced communications options including Modbus via RS485, I/O communications provide for extensive reliable data exchange.

  Multiple

  units can be connected together to meter unlimited number of circuits.

  The versatility of MCM1000 meters are ideal for multi-tenant or departmental metering applications within office towers, condominiums, apartment buildings, shopping centers and other multi-user environments.

  Features:

  ·Class 0.5 basic parameter and class 1 for active energy

  ·6 channels three phase or 18 channel single phase metering

  ·Current measuring .

  /5 or .

  /1 A (optional 333mV)

  ·Standard 35mm - 8 module DIN rail mounting

  ·Provide RS-485 MODBUS-RTU Communications

  ·Optional 6DI / 2DO for signal detect and remote control

  ·Optional external connection LCD screen, 96*96mm panel mount

  ·Optional TOU record for each monitor channel

  ·Accept customization design
