Air Quality Module Aqm 300c - China

Feature

Applications

* Long life

* Air purifier

* High sensitivity

* Air quality monitoring

* Automatic calibration

* Air ventilation system

* Comes with temperature & humidity compensation

* Low cost

Spec

* Module model: AQM-300C

* Sensor: AQS501 air quality monitoring sensor

* Gas detection: ammonia, hydrogen, alcohol, carbon

monoxide, methane, propane, Gan alkyl, styrene, propylene

glycol, phenol, toluene, ethylbenzene, xylene, formaldehyde

and other volatile organic gas, such as cigarettes, wood ,

paper burning smoke.

* Physical interface: XH2.54-4 vertical outlet

* Output data: TTL level built-in 200ohm current limiting

resistance

* Input voltage: 5.0±0.2VDC without voltage reverse

polarity protection

* Operating current: ≤80mA

* Warm-up time: 2 minutes

* Response time: ≤10 seconds

* Recovery time: ≤20 seconds

* Operating temperature: -10 --- 40C

* Operating humidity: ≤95％RH

* Storage temperature: -20 --- 60C

* Storage humidity: ≤60％RH

* Dimension: 24×20×15 L×W×H

* Weight : About 20g

* Sensitivity : 1ppm hydrogen

* Sensitivity reduction: ≤0.2%/yea r

* Life: ≥10 years

Interface definition

1, Power supply negative －

2, Power supply positive ＋

3, Output signal A

4, Output signal B
