Rf Garage Door Remote Control - Taiwan

Specification

AC Voltage： 100V/110V/120V/115V/127V/ 200V/

220V/230V/231V/240V/38 0V/415V

Loading Current：30mA

Distance： 80m/100m/160m/200m(Straig ht Line Open Space)

Password Combination： 4.2 billion

Size：130x91x48mm

Remote Storage Maximum： 120Pcs/480Pcs

Feature：

Protective slider: setting area is protected by the slide cover which is beautiful, easy to use and maintain.

Modularization: the model adopts Surface Mount Technology to increase flexibility in customizing device function.

Loop protection: when the main device is installed, it provides loop protection to prevent short circuit.

Optional pressure-sensitive protective device: When pressure sensitive roller door senses an obstruction, it immediately stops and operate reversely to prevent accidents within 0.5 seconds.

Optional Premium pressure-sensitive protection device: When it senses an obstruction, it immediately stops within 0.5 seconds and operate reversely for 5 seconds then stops again to prevent accidents.

Super Long range remote control: the remote control can control up to 200m in an obstruction-free straight line.

Roller-door operational-direction change: this can be done using remote control setting without changing the motor wiring.

Remote control lock: prevents opening of the roller door from accidental activation; and it can be disabled for public roller doors.

Roller code chip: Every time when the remote control is used, a new series of code is generated to prevent cryptanalysis by video-recording or channel scan.

The code combination has four thousand and two hundred million possibilities.

Learning remote control: It can receive and store codes transmitted by another remote control in the host (device) so that disassembling it or the host to reset is unnecessary.
