4ch 7inch Wifi Real Plug And Play Lcd Nvr Kit - China

Model RK- 720P- 4CH- WIFI( 7' )

Wireless NVR Specification

System Operating System Embedded Linux OS

AV( audio/ video) input Network Video 4CH

Network video input broadbank 20Mbps

AUdio Bitrate 64Kbps

AV( audio/ video) output HDMI input 1ch, resolution: 1024x768, 1366x768,

1440x900, 1920x1080p

AV CODEC Specification Video Resolution D1/ 720P

synch- playback 4CH

Video Control Video/ Capture mode Maual, Time, Motion

Playback mode Real time, Routine, Event

Backup USB backup

Hard Disk Type 1* SATA interface

Max Capacity 4 TB at most for each

External Interface Network Interface 1 adaptable RJ45 10M/ 100M, 1 WIFI interface

USB Interface 2 USB 2.0

Network Control Protocol UPnP ( play& plug) / SMTP( email survice) /

PPPoE ( dial- up)

DHCP ( Automatically obtain an IP address) , etc.

Others Power Supply DC12V3A

Power Consumption ( W) ≤5W( Without HDD)

Operate Temperature ( °C) - 10°C~+55°C

Working Humidity ( % ) RH 10% ~90%

Size 257mm( W) ×210mm( V) ×45mm( H)

LCD Screen Size 7 inch LCD Screen

Weight( excluding HDD) ≤1Kg

IPC Specification

Technical Parameters Sensor 1/ 4” Progressive Scan Sensor

Signal System PAL/ NTSC

Resolution 1280 x 720 16: 9 High Definition

Minimum illumination Color: 0.1 Lux; B/ W: 0.01 Lux

Shutter 1/ 25s to 1/ 25, 000s

Lens 4mm

OSD Date Time & Title

White Balance Auto

Day& Night Auto/ Color/ BW

3D- DNR Auto

Mirror/ Flip On/ Off

Frame Specification Three Streaming at the Same Time:

H.

264 128x720@ 30fps or below

H.

264 640x480@ 30fps or below

S/ N >39.1 Db

Interface RJ45/ WIFI 802.11b/ g/ n

General Specification Anti- thunder Level Standard IEC61000- 4- 5

Working Temperature/ Humidity - 10°C to+50°C/ 30% to 80% RH

Working Temperature/ Humidity - 20°C to+60°C/ 20% to 90% RH

Power Input DC12V- 1A

Power consumption ≤6W

Size 205( L) ×70( W) ×55 ( H) mm

Weight 500g

Level of Protection IP66
