1megapixel Wireless Tilt Pan Ip Camera With Tf Card Memory And Free Ddns - China

Camera structure

Model No.

H13-DAD10

System security Supports three-level account, password, user

multi-level authority management

DDNS free Built in free DDNS system

Mobile Phone platform Special mobile phone management

software

Integrated Monitoring System "Multi-view management

software, no user limitation special integrated

monitoring system, remote record"

Superiority Support PC monitoring, support most smart

phone such as iphone, android, symbian, etc.

Local memory Support up to 32G TF card memory( SD card is

not included)

System requirement Microsoft Win98 SE/ME/2000/XP, Vista

IE5.0, NET4.5, firefox, chrome

Operation system Embedded Linux OS

Video

Compression format H.

264 main profile level 3, dual

stream

Sensor CMOS 1 megapixels

Frame rate Main stream: 1-25fps second stream: 1-25fps

Resolution main stream: 720P(1280*720) second stream:

QVGA(320*240)

Video adjustment Brightness, contrast, saturation.

Minimum illumination 0.3 Lux/F1.2

S/N ratio >48DB (AGC off)

Shutter speed PAL: 1/50s- 1/100, 000s NTSC: 1/60s

-1/100, 000s auto

WB, BLC Auto

Lens Standard: 3.6mm

Audio

Compression format G.

726/G.

711

Input/Output two-way audio, one channel linear(microphone

with power supply) input /linear output

Output Audio output

Network

Network interface 10Base-T/100Base-TX Ethernet slot

Protocol "TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP,

SMTP, FTP, DHCP, DNS, DDNS, NTP,

UPNP, RTSP etc.

"

Wireless WIFI, 802.11 b/g/n

Online visitor Support 10 visitors at the same time

IP mode Dynamic IP address, static IP address, PPPOE

Compatibility Onvif

Nightvision

Filter switch Built-in IR Cut, filter switch

automatically, without color cast

Nightvision 9 Φ5 LED lights IR distance: 10m

P/T

Motor Built-in motor control

Rotation angle Horizontal: 270° vertical: 90°

Alarm

Motion detection regions support 4 Motion detection

regions

Alarm action Support Email record,

photo and record can be written into SD card

Others

Material Plastic

Use enviroment Indoor use

Power DC5V 2A

Temperature -10~50 °C

Humidity 95% RH

Packing size(mm) 170x170x170(L*W*H)

Packing weight(g) 650

Carton packing pcs/ctn, kg/ctn, carton size

Accessories Power adapter, CD, manual, warranty card,

srews, bracket, antenna

Certificate CE, FCC, ROHS, ISO
