Rf Microwave Drop In Circulator 20mhz To 20ghz Up 2000w Power Tab Connector - China

Features:

◆ Frequency Range 20MHz to 20GHz, Up to 2000W Power.

◆ Military, Space and Commercial Applications.

◆ Low insertion Loss, High Isolation, High power handling.

◆ Custom Design Available Upon Request

Specification:

Low Frequency from 20MHz to 1875MHz, FM, VHF, UHF, etc

Model No.

： UIYDC8080A

Freq.

Range( MHz) ： 20~50

BW（ Max.

） ： 10%

IL.

( dB) ： 1.5

Isolation( dB) ： 17

VSWR： 1.35

Forward Power( W) ： 50

Reverse Power( W) ： 50

Connector Type ： TAB

Temp.

( Centigrade) ： +10~+60

Dimension LxWxH( mm) ： 80x80x28

410MHz to 20GHz, GSM, CDMA, WCDMA, LTE, L.

S.

C.

X band, etc

Model No.

： UIYDC815A

Freq.

Range( GHz) ： 5.8~20.0

BW（ Max.

） ： 25%

IL.

( dB) ： 0.3

Isolation( dB) ： 23

VSWR： 1.2

Forward Power( W) ： 30

Reverse Power( W) ： 30

Temp.

( Centigrade) ： - 40~+85

Dimension LxWxH( mm) ： 8.9x15x7.8
