Wantai Stepper Motor 57bygh627 19kg Cm 3a Cnc Engraver - China
price: contact company for price
Part No: 57BYGH627 Single Shaft
Frame Size: NEMA23
Step Angle: 1.8 degree
Voltage: 3.0VDC
Current: 3.0 A/phase
Resistance: 1.0 Ohm/phase
Inductance: 3.5 mH/phase
Holding torque: 19Kg-cm
Rotor inertia: 480 g-cm2
Detent torque: 1.2 kg-cm
Number of wire leads: 4
Weight: 1KG
Length: 76mm
Front shaft diameter: 6.35mm (1/4'')
Front shaft length: 21mm round shaft
Company Contact:
- Posted By: WANTAIMOTOR
- Phone: 18852815078
- Address: No.18, Boyang Road, Jintan Area, Changzhou, Jiangsu, China, Changzhou , Jiangsu , China
- Email:
- Website: https://www.wantmotor.com
Published date: February 20, 2023 - Modified date: February 20, 2023
- Business Description: We are Professional stepper motor supplier and specializing in Hybrid Stepping Motor, DC Brushless Motor, Professional PM Stepping Motor, DC & Stepping Gear motor, CNC Stepper motor, Motor Divers and the relevant control system.
Annual turnout is more than 4 million units.
Annual turnover is more than 15 Millions USD dollars.
Our product are mainly used in Aerospace & Defense, Automation Applications, Commercial Equipment, Industrial Tool, Medical Device & Equipment, Medical Mobility, Printing & Imaging, Pump, Semiconductor Equipment, Vehicle, Milling Machine, Engraver Machine, CNC Routers Applications…etc.
of various trades.
Our products are widely sold to America, Germany, Switzerland, Italy, Russia, Arabia, Korea, South Africa, Brazil, Argentina etc over 30 countries.
Our company has powerful technology, mature technics and complete testing equipments.
As a global supplier, we make our customers satisfactory by good quality, excellent service, competitive price.
To provide cost-effective products to customers around the world is our responsibility.
