    • Three Port High Power Polarization Maintaining Fiber Isolator 100w - China

    price: 50.00 Dollar US$

    Three Port High Power Polarization Maintaining Fiber Isolator 100w

    Products Photos Catalog Port Power Photos Catalog

    Ruik's polarization maintaining optical isolator is a device, which allows the light to transmit through the passive route from input to output, while blocking the reversed direction.

    Specifications： Parameters

    Center Wavelength：1064, 1030, 980nm

    Operating Wavelength Range：±5nm

    Typ.

    Peak Isolation at 23℃：30dB

    Min.

    Isolation at 23℃：25dB

    Typ.

    Insertion Loss at 23℃：0.6dB

    Max.

    Insertion Loss at 23℃：0.8dB

    Max.

    Polarization Dependent Loss at 23℃, only for PI：0.2dB

    Min.

    Extinction Ratio at 23℃, only for PM：20dB

    Min.

    Return Loss(Input /Output)：45dB

    Max.

    Average Optical Power：100W

    Max.

    Peak Power for ns Pulse：20kW

    Max.

    Tensile Load：5N

    Package Dimension：82x38x35mm


    Operating Temperature：+10~+50℃

    Storage Temperature：0~+60℃


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020 - Modified date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
