Smd P8 Full Color Seaside Anti Corrosion Outdoor Fixed Led Screen - China

SMD P8 Full Color Seaside Anti-corrosion Outdoor Fixed LED Screen

Full Color Seaside LED Screen

P8 outdoor fixed led video wall, with it's back door and waterproof test, it can use for the high temperate application, with it's anti-corrosion test, can fix for the seaside for advertisement.

P3/P4/P5/P6/P8/P10 outdoor to meet your request.

Features of SMD P8 LED Screen:

1 - High brightness: With Kinglight and Nationstar, to ensure the led lamp quality and it’s brightness, which is up to 6000nits.

2 - Large viewing angle: Horizontal with 140degree, vertical with 120 degree, suit for outdoor large place environment.

3 - Iron cabinet and aluminum cabinet available according to the led screen installed environment, cabinet size can be customized.

4 - High refresh rate, up to 1920-3840Hz, to ensure the image quality.

5 - Hand holder and side lock design for the led cabinet, easily to carry the led cabinet and assemble them one by one.

6 - High heat dissipation: With two or four fans to fix in the back door, keep the led cabinet can be used in the high temperature application.

7 - Front service & rear service are available, can fix in any places.

8 - Long life-span up to 2-5 years.

Specification of P8 Outdoor LED Screen:

Parameter Technical of P8 Outdoor LED Video Wall Supplier

Item Model Parameter

LED Module Info.

Pixel Pitch P8 Outdoor Fixed LED Panel LED Lamp SMD3535 IC Driver MBI5124/MBI5051B/MBI5253 LED Module Size 320*160mm or 256*128mm LED Module Resolution 40*20dots or 32*16dots Color Temperature 3000-9000K Drive Mode 1/5 scan & 1/4 scan

LED Cabinet Info.

Cabinet Size 960*960*120mm or 1024*1024mm Cabinet Resolution 120*120dots or 128*64dots Cabinet Material Iron or Aluminum Cabinet LED Module Quantities 3*6=18pcs or 4*8=32pcs Cabinet Net Weight 45kg/pc or 48kg/pc IP Grade Waterproof IP65

LED Display Info.

Best Viewing Distance 8m-100m Viewing Angle H: 140°/ V: 120° Pixel Density 15625dots/㎡ Brightness 6000nits Max.

Power Consumption 747W/㎡ Ave.

Power Consumption 336W/㎡ Refresh Rate 1920Hz-3840H, can be adjusted

Control System Info.

Operating System WIN98/2000/NT/XP Control Method Synchronous display with control PC by DVI or Asynchronous with Wifi/4G/USB Control System Linsn, Nova-star, Colorlight or as you required Display Content Video, DVD, VCD, TV, picture, cartoon, graphics, texts.

etc.

Frame Frequency 50Hz or 60Hz Transmission Distance Multi mode fiber <500m, single mode fiber <30km, internet cable<100m

Operation Info.

Working Temperature -20℃--+60℃ Storage Temperature -30℃--+80℃ Input Voltage AC110V/AC220V Humidity Environment 10%-95% Lifespan 100, 000hours MTBF 10, 000hours Certificate CE, CCC, FCC, ROHS, ISO9001
