Pv Wire 2kv Solar - China
price: contact company for price
PV Wire 2kv(solar) Voltage
2KV Construction
Sino cables type PV wire 2kv is AA-8000 series Aluminum Alloy, compact stranded.
Insulation is an abrasion, moisture, heat, and sunlight resistant cross-linked polyethylene (XLP).
Copper conductor is also available.
Standard
UL4703; UL44; UL854; CSA C22.2 NO.
271; NEC Article 690, or other standards required by customers.
Features
1-40℃90℃, RoHs compliant.
2 - High-Heat, Moisture and Sunlight Resistant.
3 - VW-1 or higher required by UL.
Applications
1 - Sino cables type PV wire is primarily used for interconnection wiring of grounded and ungrounded photovoltaic power systems which do not exceed 2000 volt.
solar power applications per NEC Article 690.
2 - Rated 90℃ for exposed or concealed wiring in wet or dry locations.
3 - Rated for direct burial conduit.
Package
steel ＆ wooden reel, wooden reel, steel reel, in coils on wooden tray, or other requirements by customers.
Company Contact:
- Posted By: Jiangsu Sanqi Cable & Wire Co., Ltd,
- Phone: 0513-68971818
- Address: Rudong economic development area, Jiangsu, China , Rudong , Jiangsu , China
- Email:
Published date: April 27, 2017
- Business Description: Sino-Cable manufacture cables with AA 8000 series aluminum alloy cable, power cable, rubber cable, solar cable, xhhw-2, use-2, ser/seu, MC, MHF, UD Wire Cable.
