Power Cable Iec - China
price: contact company for price
Power Cable (IEC) Voltage
0.6/1KV Construction
Sino-cables type power cable is constructed with concentric lay stranded copper or aluminum conductor.
The conductor is extruded with PVC(polyvinyl chloride) or XLPE(cross-linked polyethylene) insulation.
The insulated conductors are cabling together with non-hygroscopic fillers inside for round shape and reinforcement tape for added strength and conformity.
A PVC outer jacket covers the entire assembly.
If for direct burial, a galvanized steel tape and an inner PVC sheath are needed between bonding tape and the outer sheath.
Standard
GB/T 12706; IEC60502, or other standards required by customers.
Features
1 - the operating temperature: -40℃90℃, for PVC insulated cable is -4070℃.
2 - When short-circuit happens(with 5s), the maximum temperature of the conductor shall not be over 250 ℃(PVC insulated cable is 160℃).
3 - Different level of fire resistant as NH, fire retardant as ZR, low smoke halogen free as WDZ, or other requirements by customers.
4 - chemical attack resistance and rat proof and termite proof.
5 - The concentric product has low impedance and excellent screening property, and meets the requirement of RoHS.
Applications
Sino-cables type power cableis suitable for electrical energy transmission of low voltage distribution circuit.
Package
in coil, steel and wooden reel, steel reel, wooden reel.
Company Contact:
- Posted By: Jiangsu Sanqi Cable & Wire Co., Ltd,
- Phone: 0513-68971818
- Address: Rudong economic development area, Jiangsu, China , Rudong , Jiangsu , China
- Email:
Published date: April 27, 2017
- Business Description: Sino-Cable manufacture cables with AA 8000 series aluminum alloy cable, power cable, rubber cable, solar cable, xhhw-2, use-2, ser/seu, MC, MHF, UD Wire Cable.
