Polarization Maintaining Optical Filter Coupler 780nm 980nm 1064nm 1310nm 1550nm 2000nm - China
price: 45.00 Dollar US$
Ruik's Polarization Maintaining Filter Coupler is one type of passive components, which divides the light into any proportions.
Other name：
filter coupler, PM Filter coupler, Polarization maintaining filter coupler, PM fiber coupler, 780nm filter coupler, 850nm filter coupler, 980nm filter coupler, 1064nm filter coupler, 1550nm filter coupler, 1030nm filter coupler, 2000nm filter coupler, 2um filter coupler Specifications： Parameter Unit Value
Type - 1x2 2x2
Type
Center Wavelength nm 1310, 1550 1064 1310, 1550 1064
Center Wavelength
nm
Operating Wavelength Range nm ±40 ±20 ±40 ±20
Operating Wavelength Range
nm
Max.
Excess Loss dB 0.7 0.8 1.0 1.2
Excess Loss
dB
Uniformity (only for 50/50) dB 0.4 0.5 0.6 0.8
Uniformity
dB
Coupling Ratio dB 01/99~50/50
Coupling Ratio
dB
Min.
Extinction Ratio at 23℃ Both axis working dB 20 20 18 18
Min.
Extinction Ratio at 23℃
Both of axis working
dB Fast axis blocked dB 22
Min.
Return Loss dB 50
Min.
Return Loss
dB
Max.
Optical Power(CW) mW 300
Max.
Optical Power(CW)
mW
Max.
Tensile Load N 5
Max.
Tensile Load
N
Fiber Type Tap Port - SMF-28E, Hi1060 or PM Panda fiber
Fiber Type
Tap Port2 Port 1 & 3 - PM Panda fiber Port1 & 3
Operating Temperature ℃ -5~+70
Operating Temperature ℃
Storage Temperature ℃ -40~+85
Storage Temperature ℃
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
