Polarization Maintaining Optical Fiber Circulator 1310nm 1550nm 2000nm - China
price: 42.00 Dollar US$
Ruik's pm circulator is one type of products, allowing the light to transmit through the route established, from port 1 to port 2, and from port 2 to port 3, blocking the reversed.
Specifications： Parameter Unit Value
Type - Type A Type B
Port Type - 3 Port 4 Port 3 Port 4 Port 3 Port 4Port
Center Wavelength nm 1310 or 1550 1310 or 1550 1064
Operating Wavelength Range nm ±20 ±20 ±5
Typ.
Insertion Loss at 23℃ dB 0.7 1.1 0.6 1.0 1.8 2.2
Max.
Insertion Loss at 23℃ dB 0.9 1.3 0.8 1.2 2.1 2.5
Typ.
Peak Isolation 23℃ dB 46 30 30
Min.
Isolation at 23℃ dB 40 20 25
Min.
Extinction Ratio at 23℃ dB 22 20 20
Min.
Cross Talk dB 50
Min.
Return Loss dB 50
Max.
Optical Power(CW) mW 300
Max.
Tensile Load N 5
Operating Temperature ℃ -5~+70
Storage Temperature ℃ -40~+85
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
