Pm Or Singlemode Mode Field Adapter Mfa - China

Mode Field Adapters (MFA) can be used for high power fiber lasers and fiber amplifiers.

These devices can be used to connect two fibers with different core diameters and numerical apertures (NA).

Specifications

Parameters Value

Port Configuration 1x1

Signal Wavelength 1030~1080nm or 1450~1600nm

SMA Fiber 6/125 10/125 10/125 6/125 20/250 LMA Fiber 1 0/125 20/125 25/250 20/400 30/250 Signal IL for Forward Route 0.3dB 0.4dB 0.5dB 0.5dB 0.2dB Signal IL for Backward Route 0.3dB 0.5dB 0.7dB 0.7dB 0.2dB Total Handling Power 10W

Polarization Extinction Ratio 18dB(PM Fiber Type)

Return Loss 45dB

Package Dimension D1, D2, D3, D4, D5, D6, D7

Operating Temperature -5~+70

Storage Temperature -40~+85 Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm.

We also provide Customized components to our customers.

High power Optical Fiber Components:

-Optical Fiber Isolator, up 100W;

-Free Space Isolator, up to 100W;

-Optical Circulator, up to 30W;

-Pump Laser Protector;

-Band Pass Filter;

-Nx1 Pump Combiner;

-Cladding Power Stripper;

-Mode Field Adapter;

-(N+1)x1 Pump & Signal Combiner, 200W/port; Polarization Maintaining Fiber Components:

-In Line Polarizer/Depolarizer;


-In Line Faraday Isolator;

-Optical Circulator;

-Fused WDM / Coupler;

-Filter WDM / Coupler;

-Fiber DWDM

-Fiber Mirror;

-Faraday Rotator;

-Fiber Patch cord / Jumper;

-PLC Splitter Module;

-Tap / WDM / Isolator Hybrid;

Manual Variable Optical Attenuator;

-1x2 Polarization Beam Splitter / Combiner (PBS/C)

-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)
