Pm Fiber Tap Isolator 300mw 1064nm 1550nm - China
price: 45.00 Dollar US$
Ruik's Tap Isolator is the device hybrid of coupler and isolator.
Specifications: Parameter Unit Value
Stage - Single Dual Single Dual
Operating Wavelength Range nm 1550±15 1064±5
Max.
Excess Loss dB 1.0 1.2 2.2 3.5
Signal Tap Ratio % 1±0.2%, 5±1%, 50±2%
Typ.
Peak Isolation dB 40 52 40 52
Min.
Isolation at 23℃ dB 28 45 28 45
Min.
Extinction Ratio at 23℃ dB 20
Min.
Return Loss dB 50
Max.
Optical Power(CW) mW 500
Max.
Tensile Load N 5
Operating Temperature ℃ 0~+70
Storage Temperature ℃ -40~+85
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
