Pm Fiber Isolator Wdm Hybrid 1550 980nm - China
price: 45.00 Dollar US$
Ruik's Isolator & WDM Hybrid is a device to combine the functions of isolator and WDM device.
Specifications： Parameter Unit Value
Stage - Single Dual Single Dual
Signal Channel Signal Wavelength Range nm 1064±10 1550±15 Max.
Insertion Loss dB 2.6 3.8 0.9 1.0 Typ.
Peak Signal Reversed Isolation, at 23℃ dB 40 52 40 52 Min.
Signal Reversed Isolation, at 23℃ dB 28 45 28 45 Min.
Isolation (Com to Pass @ Ref band Wavelength) dB 30 Min.
Extinction Ratio at 23℃ dB 20
Reflection Channel Wavelength Range nm 960~990 Max.
Insertion Loss dB 0.6 Min.
Isolation (Com to Ref @ Pass band Wavelength) dB 15 Min.
Extinction Ratio at 23℃ dB 18
Min.
Return Loss dB 50
Max.
Insertion Loss Thermal Stability dB/℃ 0.005
Max.
Optical Power(CW) mW 300
Max.
Tensile Load N 5
Operating Temperature ℃ -5~+70
Storage Temperature ℃ -40~+85
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
