  • Pm Fiber Isolator Polarization Beam Splitter Combiner Hybrid Ipbs C 1064nm 1310nm 1550nm 2um - China

    price: 45.00 Dollar US$

    Ruik's Isolator & Polarization Beam Combiner Hybrid is one type of passive component, which combine the functions of Isolator and PBS.

    Specifications: Parameters Unit Values

    Stage - Dual Single

    Center Wavelength nm 1310, 1550 1310, 1550 1064

    Operating Wavelength Range nm ±20 ±20 ±5

    Typ.

    Insertion Loss at 23℃ dB 0.55 0.45 1.8

    Max.

    Insertion Loss at 23℃ dB 0.80 0.70 2.1

    Typ.

    Reversed Isolation at 23℃(Port 3 to Port1 or 2) dB 51 35 35

    Min.

    Isolation at 23℃(Port 3 to Port1 or 2) dB 42 20 25

    Min.

    Extinction Ratio at 23℃ dB 25 20 20

    Directivity dB 50

    Min.

    Return Loss dB 50

    Max.

    Optical Power(CW) mW 300

    Max.

    Tensile Load N 5

    Fiber Type Port1 & 2 - PM Panda fiber Port3 - PM Panda fiber or SMF-28E or Hi1060

    Operating Temperature ℃ -5~+70

    Storage Temperature ℃ -40~+85


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
