Mhf Aluminum Alloy Cable - China
price: contact company for price
Voltage
600V or less Construction
Sino-cables MHF type consists of four quadruplexed type RHH or RHW-2 or USE-2 with AA-8000 series, Aluminum Alloy compacted conductors and cross-linked polyethylene (XLP) insulation.
The conductors are cabled together with a green XLP insulted aluminum ground.
The grounded (neutral) conductor is identified by a longitudinal white stripe to eliminate the need for field marking per the NEC.
Standard
UL 44, UL 854, Federal Specification A-A-59544, requirements of the NEC, and other standards required by customers.
Features
1-40℃90℃
2 - High-Heat and Moisture and Sunlight Resistant.
3 - VW-1 or higher required by UL.
Applications
1 - Sino-cables type Mobile Home Feeder(MHF) is intended for the connection of mobile homes to a supply of electricity where permanent wiring is required as specified in the NEC in raceways and underground installations.
2 - Suitable for direct burial in earth at conductor temperatures not to exceed 90℃ in wet or dry locations.
3 - Three sizes available (with and without reduced neutral): 100, 150, and 200 ampere ratings.
Package
steel & wooden reel, wooden reel, steel reel, in coils on wooden tray, or other requirements by customers.
Company Contact:
- Posted By: Jiangsu Sanqi Cable & Wire Co., Ltd,
- Phone: 0513-68971818
- Address: Rudong economic development area, Jiangsu, China , Rudong , Jiangsu , China
- Email:
Published date: April 27, 2017
- Business Description: Sino-Cable manufacture cables with AA 8000 series aluminum alloy cable, power cable, rubber cable, solar cable, xhhw-2, use-2, ser/seu, MC, MHF, UD Wire Cable.
