Klw M71g5 001 Z Unit Assy - China

KLW-M71G5-001 Z UNIT ASSY www dot smt-cn dot com

sale at hysmt dot cn Other yamaha parts:

No.

Part No.

Part Name Q'ty Remarks Date of change Revised No.

Compati.

1 KGA-M1101-00X BASE 1

2 KGA-M1120-00X PLATE 10 1 CONNECTER

2-1 KGA-M1120-01X PLATE 10(CONNECTOR) 1 2001/11/5 M1X0008 NG

3 KV7-M1112-00X PLATE 2 1

4 KGA-M1113-00X PLATE 3 1 VALVE

5 KV7-M1114-00X PLATE 4 1 I/O

6 KV7-M1115-00X PLATE 5 1 AIR

7 KM0-M1141-00X MANUFOLD 2

8 KG7-M1342-01X BRACKET F/D 1

9 KG7-M8501-00X AIR FILTER 1

10 KV8-M8502-00X MIST FILTER 1 MF400-A

11 KV8-M8503-00X MODULE ADAPTER 1

12 KG7-M8504-00X REGULATOR 1 R300-03

13 KG7-M8512-00X JOINT 1

14 KG7-M8513-00X JOINT 1

15 KM0-M8582-00X VALVE 1 040M12AJ1-7

16 KG7-M8596-00X PRESSURE GAUGE 1

17 KV7-M1118-00X PLATE 8 1

18 KV7-M1125-00X PLATE CLAMP 1

19 KG2-M1128-00X BRACKET SPEED CONT.

1

20 KM0-M1142-00X CASTER 6 (OPTION)

twenty one

KGA-M1151-00X PLATE, SIDE 1 1 for STD 2003/8/21 M380030

KGA-M1151-10X PLATE, SIDE 1 1 for UPS 2003/8/21 M380030

twenty two

KM0-M1152-01X PLATE SIDE 2 1 for STD 2003/8/21 M380030

For UPS 2003/8/21 M380030

23 KM0-M1153-01X PLATE SIDE 3 1 2003/8/21 M380030

24 KM0-M1154-01X PLATE BOTOM 1 2

25 $SL12-03 JOINT 4

26 $SLY10-03 JOINT 1

27

28 $TL4-02 JOINT 1

29 $UEDW10-8 JOINT 1

30 $U D10-8 JOINT 1

31 $SL8-01 JOINT 1

32 $KM-11 MUFFLER 1

33 $TSS4-01 JOINT 12

34 $TSH8-01 JOINT 2

35 KGA-M1180-00X LEVELING BOLT ASSY.

4

36 KHA-M1180-00X LEVELING BOLT ASSY.

2

37 K40-M8598-00X PLUG 1 2

38 91C00-03210 SPACER 28 M3X10L

38-1 90563-03J100 SPACER BOLT 28 2001/9/1 M180147 OK

39 KH5-M8501-00X EXHAUST VALVE 1

40 $KM-23 MUFFLER 1

41 KV7-M1154-00X BRKT.

POWER SUPPLY 1

42 KV7-M1161-00X PLATE 11 1 TRANS

43 KV7-M1113-10X PLATE 3-1 1 REG

43-1 KV7-M1113-11X PLATE 3-1(REGULATOR) 1 2003/8/1 M370176 OK

44 KV7-M1153-00X PLATE SIDE 3 1

45 KV7-M111A-00X BRACKET.

GAUGE 1

46 $UED8-4 JOINT 1

47 $UP8 JOINT 1

48 $UP4 JOINT 3

49 $UY8 JOINT 3

50 KGA-M112B-00X PLATE, PRINTER 1

50-1 Delete 2002/10/7 M1X0008

51 KGA-M4126-00X GUIDE RAIL L ASSY.

1

51-1 KGA-M4126-01X GUIDE RAIL L ASSY 1 2002/10/7 M200012 NG

52 KGA-M4127-00X GUIDE RAIL R ASSY.

1

52-1 KGA-M4127-01X GUIDE RAIL R ASSY 1 2002/10/7 M200012 NG

53 90201-063A5 WASHER, PLAIN 2

54 KV7-M112A-00X PLATE SP 1

54-1 Delete 2002/10/7 M1X0008

55 KM8-M117A-00X PLUG 40 M8

55-1 Delete 2002/1/28 M210122

56 KM8-M117B-00X PLUG 104 M6

56-1 Delete 2002/1/28 M210122

57 98903-03006 SCREW BINDING HEAD 12

58 90159-04J01 SCREW, W/WASHER 9

58-1 90990-12J001 SCREW BIN.

HEAD W/W 1 2002/9/11 M290029 OK

59 98903-04012 SCREW BINDING HEAD 2

60 98903-05008 SCREW BINDING HEAD 38

61 97601-05310 SCREW PAN HEAD (+) W/W 53

62 91314-03025 BOLT HEX.

SOCKET HEAD 4

63 91314-04008 BOLT HEX.

SOCKET HEAD 2

64 91314-05008 BOLT HEX.

SOCKET HEAD 36

65 91314-05014 BOLT HEX.

SOCKET HEAD 2

66 91314-06016 BOLT HEX.

SOCKET HEAD 3

67 97004-08012 BOLT HEXAGON 24 (OPTION)

68 KV8-M8502-40X MIST FILTER ELEMENT 1

69 KG7-M8501-40X AIR FILTER ELEMENT 1

70 KGA-M1155-03X BRACKET, UPS 1

71 KGA-M1156-03X PLATE, UPS 1

72 KGA-M1157-03X BRACKET 2, UPS 1

73 KGA-M1158-03X COVER, HARNESS 1

74 KV7-M1515-00X PLATE, RUBBER 1

75 KG2-M8582-40X VALVE 1 spare
