Hybrid Slip Ring Manufactured In China - China
price: 689.00 Dollar US$
Hybrid slip ring is designed for setup at the end of shaft or side of the machine, fit for passing fluid + signal or low current power.
The slip ring is set in the body of rotary joint, and the wires of rotor lead out from the center.
Rotor side has flanges for setup.
(More product information welcome to visit slipring.
net.
) Feature: 1) High quality bearing on both sides of shaft for smoothly operating;
2) High quality sealing materials for long life circle;
3) Special finished shaft provides a excellent wear resistance;
4) Al, Bass, stainless steel body for option;
5) Specially designed leak detection holes;
6) No need to maintain.
Technical spec:
Speed
100Rpm
Operate temperature
-30~90℃
protect degree
IP54
Housing
Al alloy Part A: (Electornic Slip Rings)
Channels
12 rings(for signal)
Operation Voltage
0~240VAC/DC
Current
2A/Ring
Contact material
Precious Metal
Electric Nosice
Max.
40m Ω
Dielectric strength
500VAC@50Hz, 60s
Insulation resistance
500MΩ @600VDC
Part B: (Rotary Joint)
Channels
2 Ways
Pressure
1.6Mpa Max
Media
compressed air/ vacuum Our products are widely used in: Security, Factory Automation, Electric Instrumentation, Medical, Aerospace, Marine, Civil and Military Fields.
Such as: Crane, Giant Wheel, Cotton Picker, Medical Equipment, Detector, Rotary Tables, Robots, Strander, Webcam, Automatic Revolving Door, Exhibit / Display Equipment, Food Manufacturing Machine, Packaging Machine, Amusement Equipment, Irrigation Machine, Heated Rollers etc.
More product information welcome to visit our website.
Company Contact:
- Posted By: Victory-way Electronic(Shenzhen) Co., Ltd
- Phone: +86-755-2780 6979
- Address: BLD.D, Hejing Industrial Park, Heping Fuyong, Baoan District Shenzhen,China, Shenzhen , Guangdong , China
- Email:
Published date: July 16, 2018
- Business Description: Victory-way Electronic(Shenzhen) Co., Ltd. is a high-technology company which focuses on R&D and production of industrial electrical slip ring, created by senior engineers with many years of conductive slip ring application and development experience.
So we can learn the demands of customers better and provide the best solution in the shortest time to help customers shorten development time.
We design, develop and produce fiber composite (FORJ), electrical liquid mixture, high-frequency combinations, explosion-proof slip rings, waveguide combination of slip rings, etc.
and we can provide the electrical contact devices in varieties of working conditions, from the underwater environment to the high altitudes, from the alpine zone to the high temperature environment, and even for the explosive condition.
At present, our products are applied in the fields of security, industrial automation, military, environmental protection and so on.
Excellent performance and reliable quality make our conductive slip ring exported to developed industrial countries, such as Japan, USA, Europe etc.
Our products are very popular with customers and we are honored to be privileged the only supplier of slip ring for some customers of the high reliability requirement.
We will continue to work hard to provide high quality conductive slip ring and the best solutions to customers.
Our Products:
- pcb slip ring for automatic equipment vsp pb
- slip ring in waste water processing system
- standard capsule slip ring with 12 channels in cctv monitoring system vsr sc12
- standard capsule slip ring 24 ways for rotary tables
- four channels high current slip ring plus in robots packaging or medical equipment
