High Power Polarization Maintaining Optical Fiber Faraday Rotator Mirror 850nm 980nm 1030nm 1064nm - China
price: 50.00 Dollar US$
Faraday rotators change the polarization state of light traveling through it.
Other name:
Fiber Mirror, Faraday Mirror, Faraday Rotator Mirror, PM Fiber Mirror, PM faraday mirror, 1064nm faraday mirror, 1030nm faraday mirror, high power faraday mirror, 850nm faraday mirror Parameters: Center Wavelength:995nm
Operating Wavelength Width:±5nm
Max.
Insertion Loss:1.5dB
Faraday Rotation Angle for CWL:45deg
Max.
Rotation Angle Tolerance at 23 ℃ for CWL:±3deg
Max.
Polarization Dependent Loss at 23 ℃, only for PI:0.15dB
Min.
Extinction Ratio at 23 ℃, only for PM:20dB
Max.
Power Handling:0.5, 1, .
5, 10
Max.
Tensile Load:5
Operating Temperature:-5~+70℃
Storage Temperature:-40~+85℃
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
