  • High Power Pm Optical Tap Isolator Wdm Hybrid 980 1064nm - China

    price: 50.00 Dollar US$

    Ruik's Tap & Isolator & WDM Hybrid is a device to combine the functions of coupler, isolator and WDM device.

    Other name:

    Tap/Isolator/WDM Hybrid, Optical Tap Isolator WDM Hybrid, 980/1550nm WDM/Tap Coupler/Isolator, PM Fiber Tap Isolator WDM Hybrid, 980/1064nm PM WDM/Tap/Isolator Specifications

    Parameter Unit Value Stage - Single Dual Single Dual Signal Wavelength nm 1064±5 1550±15

    Signal Wavelength Range nm 1020~1080 1520~1580

    Max.

    Excess Loss, λc, at 23℃ (Input to Output) dB 2.5 3.5 1.3 1.4

    Min.

    Signal Isolation, λc, ±15 at 23℃(Output to Input) dB 35 45 28 45

    Isolation for Channels Signal Channel dB 30 Pump Channel dB 12

    Tap Ratio % 1~50

    Pump Wavelength Range nm 980±10

    Max.

    Insertion Loss (Pump Channel) dB 0.7

    Min.

    Extinction Ratio at 23℃, only for PM Channel dB 20

    Min.

    Return Loss dB 50

    Max.

    Optical Power(CW) mW 300

    Max.

    Tensile Load N 5

    Operating Temperature ℃ -5~+50

    Storage Temperature ℃ -40~+85


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
