    • High Power Pm Optical Fiber Isolator 980nm 1030nm 1064nm 10w 20w 50w - China

    price: 60.00 Dollar US$

    High Power Pm Optical Fiber Isolator 980nm 1030nm 1064nm 10w 20w 50w

    Products Photos Catalog Power Optical Fiber Photos Catalog

    Ruik's polarization maintaining optical isolator is a device, which allows the light to transmit through the passive route from input to output, while blocking the reversed direction Other name：

    PM Isolator, High Power Isolator, Optical Isolator, PM optical Isolator, Polarization Maintaining Isolator, In-line Isolator, Free space isolator, PM fiber isolator, high power fiber optic isolator, fiber isolator 1064, faraday isolator, 1064nm isolator, 980nm isolator, optical isolator 850nm, fiber isolator 980nm, 1030nm isolator, optical isolator 1550nm Parameters：

    Center Wavelength (nm) 1064 or 1030 or 980 or 915 or 850 or 780

    Operating Wavelength Range (nm) ±5

    Typ.

    Peak Isolation at 23℃ (dB) 30

    Min.

    Isolation at 23℃ (dB) 25

    Typ.

    Insertion Loss at 23℃ (dB) 0.8

    Max.

    Insertion Loss at 23℃ (dB) 1.0

    Max.

    Polarization Dependent Loss at 23℃, only for PI (dB) 0.15

    Min.

    Extinction Ratio at 23℃, only for PM (dB) 20

    Min.

    Return Loss(Input /Output) (dB) 45

    Max.

    Average Optical Power (W) 10 or Specified

    Max.

    Peak Power for ns Pulse (kW) 10 or Specified

    Max.

    Tensile Load (N) 5

    Package Dimension (mm) 58x28x26

    Operating Temperature (℃) +10~+50

    Storage Temperature (℃) 0~+60


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
