High Power Pm Optical Fiber Isolator 1310nm 1550nm 2000nm - China

Ruik's polarization maintaining optical isolator is a device, which allows the light to transmit through the passive route from input to output, while blocking the reversed direction.

Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm.

We also provide Customized components to our customers.

Specifications

Parameter Unit Value

Stage - Single Dual

Grade - P A P A

Center Wavelength nm 1310 or 1550

Operating Wavelength Range nm ±20

Typ.

Peak Isolation at 23℃ dB 42 40 58 55

Min.

Isolation at 23℃ dB 28 26 48 45

Typ.

Insertion Loss at 23℃ dB 0.4 0.5 0.5 0.6

Max.

Insertion Loss at 23℃ dB 0.55 0.65 0.65 0.8

Min.

Extinction Ratio at 23℃(only for Both Axis Working) dB 20 18 20 18

Min.

Extinction Ratio at 23℃(only for Fast Axis Blocked)

fa) dB 25 23 25 23

Max.

Polarization Dependent Los dB 0.15

Min.

Return Loss (input/output) dB 50/50

Max.

Tensile Load N 5

Operating Temperature ℃ -5~+70

Storage Temperature ℃ -40~+85 High power Optical Fiber Components:

-Optical Fiber Isolator, up 100W;

-Free Space Isolator, up to 100W;

-Optical Circulator, up to 30W;

-Pump Laser Protector;

-Band Pass Filter;

-Nx1 Pump Combiner;

-Cladding Power Stripper;

-Mode Field Adapter;

-(N+1)x1 Pump & Signal Combiner, 200W/port; Polarization Maintaining Fiber Components:

-In Line Polarizer/Depolarizer;


-In Line Faraday Isolator;

-Optical Circulator;

-Fused WDM / Coupler;

-Filter WDM / Coupler;

-Fiber DWDM

-Fiber Mirror;

-Faraday Rotator;

-Fiber Patch cord / Jumper;

-PLC Splitter Module;

-Tap / WDM / Isolator Hybrid;

Manual Variable Optical Attenuator;

-1x2 Polarization Beam Splitter / Combiner (PBS/C)

-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)
