    • High Power Optical Pm Band Pass Filter 1030nm 1064nm 1550nm - China

    price: 50.00 Dollar US$

    High Power Optical Pm Band Pass Filter 1030nm 1064nm 1550nm

    Products Photos Catalog Power Optical Band Photos Catalog

    Ruik's bandpass filter device is designed to transmitt the light of narrow bandwidth, blocking the others.

    BPF is applied in fiber laser.

    Other name：

    PM Bandpass Filter, 1064nm band pass filter, 1550nm bandpass filter, PM 1064nm Fiber Bandpass filter, 1030nm bandpass filter Parameter Unit Value

    Center Wavelength nm 976, 1030, 1064, 1550

    Min.

    Pass Band Width (@-0.5dB) nm As Customized

    Max.

    Stop Bandwidth (@-25dB) nm As Customized

    Max.

    Insertion Loss of Pass band dB 0.8

    Max.

    Polarization Dependent Loss at 23℃, only for PI dB 0.15

    Min.

    Extinction Ratio at 23℃, only for PM dB 20

    Min.

    Return loss dB 50

    Max.

    Power Handling (CW) W 20 or Specified

    Max.

    Peak Power for ns Pulse kW 10 or Specified

    Max.

    Tensile Load N 5

    Operating Temperature ℃ 0 ~ +65

    Storage Temperature ℃ -40 ~ +85


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
