High Power Multi Mode Pm Pump Laser Protector - China
price: 50.00 Dollar US$
Ruik's pump laser protector is one device, which used for blocking the reversed light from sigal, in order to protect the pump diode.
Other name: MM pump laser protector, pump laser protector, HP Pump Laser Protector, Pump protector, multimode pump laser protector, single mode pump laser protector, 980nm singlemode pump laser protector, 975nm SM pump laser protector, PM pump laser protector Parameters:
Pass Band Wavelength Range (nm) 900~990, or Specified
Max.
Insertion Loss over Pass Band Wavelength (dB) 0.7
Blocked Band Wavelength Range (nm) 1020~1100, or 1500~1600, or Specified
Min.
Isolation (dB) 25
Max.
Polarization Dependent Loss (dB) 0.15
Min.
Return Loss (dB) 30
Max.
Power Handling (CW) (W) 30
Max.
Wavelength Thermal Stability (nm/℃) 0.003
Max.
Insertion Loss Thermal Stability (dB/℃) 0.005
Fiber Type:Multi-mode fiber: 105/125, 62.5/125, 50/125um
Operating Temperature (℃) 0~+70 Storage Temperature (℃) -40~+85
Company Contact:
- Posted By: Ruik-tech Communication Co., LTD
- Phone: 18929412926
- Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China
- Email:
- Website: https://www.ruik-tech.com
Published date: April 12, 2020
- Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.
We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.
Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.
We also provide Customized components to our customers.
High power Optical Fiber Components:
- Optical Fiber Isolator, up 100W
- Free Space Isolator, up to 100W
- Optical Circulator, up to 30W
- Pump Laser Protector
- Band Pass Filter
- Nx1 Pump Combiner
- Cladding Power Stripper
- Mode Field Adapter
- (N+1)x1 Pump & Signal Combiner, 200W/port
Polarization Maintaining Fiber Components:
- In Line Polarizer/Depolarizer
- In Line Faraday Isolator
- Optical Circulator
- Fused WDM / Coupler
- Filter WDM / Coupler
- Fiber DWDM
- Fiber Mirror
- Faraday Rotator
