Flexible Pcb Fpc For Lcd Connector - China

Electronic PI Flexible PCB

- HASL surface finish and 0.25mm hole size aluminum electronic board - PCB & PCBA Service

- Contact manufacturing

- ROSH.

ISO9001, SGS, UL Certificate

- SMT&PCBA one-stop source

- Competitive Price, High Quality, Good Service

1 - Specification of PCB Manufacturing

1 Description PCB Specification

2 Material FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum

3 Layer 1-20

4 Board Thickness 0.2mm- 4.0mm

5 Board Thickness Tolerance +/-10%

6 Copper thickness 17.5um-175um (0.5oz-5oz)

7 Min Trace Width 0.15mm

8 Min Space Width 0.15mm

9 Min Drilling Dia 0.2mm

10 PTH copper thickness 0.4-2mil(10-50um)

11 Tolerance of Etching ±1mil(±25um)

12 V-cut angle 25°, 30°, 45°, 60°

13 Pearl Strength of line ≥ 6lb/in(≥ 107g/mm)

14 Impedance control and tolerance 50Ω±10%

15 Twist&Wrap ≤ 0.5%

16 Soldermask Green, Red, Blue, White, Black, Yellow

17 Surface Finish/Plating HASL/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG

18 Certificate ROSH.

ISO9001, SGS, UL Certificate

19 File Protel 99se/P-CAD/Autocad/Cam350

2 - Detailed Terms for Pcb Assembly

1 Quantity Prototype&Low Volume PCB Assembly, from 1 Board to 250, is for specialty, but we can handle orders up to 1000

2 Type of Assembly SMT and Thru-hole

3 Solder Type Water Soluble Solder Paste, Leaded and Lead-Free

4 Components Passives Down to 0201 Size BGA and VFBGA Leadless Chip Carries/CSP Double-Sided SMT Assembly Fine Pitch to 08 Mils BGA Repair and Reball Part Removal and Replacement-Same Day Service

5 Bare Board Size Smallest: 0.25x0.25 Inches Largest: 20x20 Inches

6 File Formats Bill of Materials Gerber Files Pick-N-Place File(XYRS)

7 Type of Service Turn-Key, Partial Turn-Key or Consignment

8 Component Packaging Cut Tape Tube Reels Loose Parts

9 Turn Time Same Day Service to 15 day service

10 Testing Flying Probe test XRAY Inspection AOI Test

3 - PCB or PCB Assembly files requests

1 - Gerber files of the bare PCB board

2 - BOM (Bill of material) for assembly, To short the lead time, please kindly advise us if there is any acceptable

components substitution.

3 - Testing Guide & Test Fixtures if necessary

4 - Programming files & Programming tool if necessary 5 - Schematic if necessary
