Desktop Constant Temperature Humidity Storage Test Chamber - China

Desktop constant temperature and humidity storage cabinet(YCT-080) Introduction&Applicat ion: Desktop constant temperature and humidity storage cabinet ( climatic/ climate/ environment/environmental test chambers) simulate the effects that a range of temperature and humidity conditions have on a product or material, for example telecommunications equipment or photovoltaic solar panels that are exposed to outdoor temperature and humidity conditions.

They have applications in industries as disparate as food science, semiconductors, and military quality assurance.

A good temperature humidity chamber is essential for evaluating potential success or failure of a product in the field.

Climate test chambers come in a variety of sizes, from a small box that fits on the bench top to a room-sized chamber for large objects or for testing large batches of product simultaneously.

Temperature ranges from 0° C to 150° C and relative humidity ranges between 20% and 98% are available.

A climate test chamber can also be used when constant climate conditions (temperature and/or humidity) are needed for product testing.

Feature: 1 Large system capacity: 120 patterns*1200 steps 2 Circulation Setting: Max.

9999 cycles.

3 PID+SSR/SCR controller.

4 Curves drawing.

5 Safety device 6 RS-232&RS-485 communication interface.

7 CE certification 8 Touch screen controller 9 Best after sales service: One year free parts maintenance.

10 Meet international test standards.

11 Customization is available & welcomed.

Technical parameters, please read below table.

More details about the specification, please contact us, thanks for your attention.

Except Desktop constant temperature and humidity storage cabinet, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply: Precision Oven Tester, Triple Type Temp.

& Humi.

Chamber, Temp.

&Humi.

Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp.

Humi.

&Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

Welcome to enquire and purchase! Model YCT-080

Internal Dim.

W×H×D(mm) 400×500×400

External Dim.

W×H×D(mm) 1150×1000×1150

Temperature Range 0ºC~+150ºC

Humidity Range 20%HR ~98%HR Ferformance Temp.

&Humi Fluctuation ±0.2ºC;±0.5%RH

Temp.

&Humi Uniformity ±1.5ºC;±2.5%RH

Indication Resolution 0.1ºC;0.1%RH Heat-at Time(20ºC~HT) ºC 100 150

min 30 40

Pull-down

Time(20ºC~LT) ºC 0 -20 -40 min 25 40 50 Material Exterior Stainless steel plate+Powder Coated

Interior SUS#304 stainless steel piate

Insulation PU & Fiberglass wool

Systems Cirulation Siroco fan

Heating SUS#304 stainless steel high-speed heater

Humidifying Surface evaporating system

Cooling Airtight compressor+vaporator fins+air-cooling condenser

Dehumidifying ADP Critical dewpoint cooling/dehumidifying method

Controller Digital electronic indicatrs+S.S.R.

With PIDautomatic calculation capabilty

Other Components Vacuum glass inspectin window, cable port( 60mm), control status indicator lights, chamber lamp, experment separation shelves (freely adjustable 2pcs)

Safety Devices Overheating prevention circuit-breaker, compressor overload protection, control system overload protection, humidifying system overheading drying out prevention, breakdown indicator light

Power Source[K.W.] AC 1¢ 220V 60/50Hz
