2x2 Pm Optical Fused Fiber Wdm - China

This product can also be used to multiplex other wavelengths.

including 980/1030 nm (pulsed laser applications) and 1064/1550 nm (Erbium-Ytterbium pumping).

Low power (300 mW, 500 mW) and high power (20W) handling are available.

They are ideal for polarization maintaining fiber amplifiers, fiber lasers, and high speed communication system and instrumentation applications.

Specifications： Parameter

Type：980/1550

Operating Bandwidth：±15nm

Max.

Insertion Loss Signal Port：0.5dB

Pump Port：0.5dB

Min.

Extinction Ratio：20dB

Min, Isolation：18dB

Min.

Directivity：55dB

Max.

Return Loss：50dB

Max.

Optical Power(CW)：1W

Fiber Type：PM Panda Fiber

Package Dimension：3*54mm(bare fiber, 0.9mm loose tube)

Operating Temperature：-5~+65℃

Storage Temperature：-40~+85℃

Company Contact:

• Posted By: Ruik-tech Communication Co., LTD

• Phone: 18929412926

• Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

• Email:

• Website: https://www.ruik-tech.com

• Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

  We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

  Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

  We also provide Customized components to our customers.

  High power Optical Fiber Components:

  - Optical Fiber Isolator, up 100W

  - Free Space Isolator, up to 100W

  - Optical Circulator, up to 30W

  - Pump Laser Protector

  - Band Pass Filter

  - Nx1 Pump Combiner

  - Cladding Power Stripper

  - Mode Field Adapter

  - (N+1)x1 Pump & Signal Combiner, 200W/port

  Polarization Maintaining Fiber Components:

  - In Line Polarizer/Depolarizer

  - In Line Faraday Isolator

  - Optical Circulator

  - Fused WDM / Coupler

  - Filter WDM / Coupler

  - Fiber DWDM

  - Fiber Mirror

  - Faraday Rotator
