1064nm Pm Optical Fiber Faraday Isolator - China

Ruik's polarization maintaining optical isolator is a device, which allows the light to transmit through the passive route from input to output, while blocking the reversed direction.

Specifications

Parameter Unit Value

Stage - Single Dual

Grade - P A P A

Center Wavelength nm 1064

Operating Wavelength Range nm ±5

Typ.

Peak Isolation dB 40 38 55 52

Min.

Isolation at 23℃ dB 32 28 45 42

Typ.

Insertion Loss at 23℃ dB 1.5 1.6 2.4 2.6

Max.

Insertion Loss at 23℃ dB 1.8 2.2 3.2 3.4

Min.

Return Loss (input/output) dB 50/50 50/50 50/50 50/50

Min.

Extinction Ratio at 23℃(only for B type) dB 20 18 20 18

Min.

Extinction Ratio at 23℃(only for F type) dB 22 20 22 20

Max.

Optical Power(CW) mW 300

Max.

Tensile Load N 5

Fiber Type - PM Panda fiber

Operating Temperature ℃ -5~+50

Storage Temperature ℃ -40~+85 Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm.

We also provide Customized components to our customers.

High power Optical Fiber Components:

-Optical Fiber Isolator, up 100W;

-Free Space Isolator, up to 100W;

-Optical Circulator, up to 30W;

-Pump Laser Protector;

-Band Pass Filter;

-Nx1 Pump Combiner;

-Cladding Power Stripper;

-Mode Field Adapter;

-(N+1)x1 Pump & Signal Combiner, 200W/port; Polarization Maintaining Fiber Components:

-In Line Polarizer/Depolarizer;


-In Line Faraday Isolator;

-Optical Circulator;

-Fused WDM / Coupler;

-Filter WDM / Coupler;

-Fiber DWDM

-Fiber Mirror;

-Faraday Rotator;

-Fiber Patch cord / Jumper;

-PLC Splitter Module;

-Tap / WDM / Isolator Hybrid;

Manual Variable Optical Attenuator;

-1x2 Polarization Beam Splitter / Combiner (PBS/C)

-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)
