1000w 24v Wind Power Generator - China

The 5 blades horizontal axis wind turbine has a smart blade aerodynamics braking and electromagnetic speed limitation function.

Product Description

1 .

Descriptions

The 5 blades horizontal axis wind turbine has a smart blade aerodynamics braking and electromagnetic speed limitation function.

Patented aerofoil 5 blades design with true symmetrical and twisted aerodynamic feature which ensures rotor capture maximum power from wind and operates in amazingly low noise and minimal vibration.

True symmetrical and balanced aerofoil blade ensure rotor matching with generator perfectly.

Large ratio of tip section chord to root section chord and variable chord airfoil blade ensures rotor start-up easily and running smoothly with high torque and RPM at lower wind condition.

Aerodynamic blades designed with over-speed braking system to make sure generator well protected in higher wind.

Reinforced Glass-Fiber Nylon is using advanced thermoplastic engineering and precision injection molding technology for higher strength, flexibility and reliability.

Our wind turbine with minimal vibration and low noise could be mounted on rooftop safely and its operation won’t affect resident.

2 - Applications

1000W Horizontal Axis Wind Turbine 5 Blades With Aerodynamic Braking suitable for residential and commercial applications both for off grid and on grid power systems.

The unit provides a durable, reliable usage for off-grid home, island hostel, telecoms repeaters, wind solar charging station, remote security monitoring and communication facilities, remote holiday hotel, military base camp, off-grid fishing or hunting cabins, etc.

3 - Special features - Minimal vibration and low noise operation

Everything with moving parts will make some noise and vibration, and wind turbines are no exception, most noise and vibration are caused by turbine blades rotation in the wind and generator resonates with rotor and tower, HY Energy well designed wind turbine could work quietly in both low and high wind.

● The blades have exceptional consistency and aerodynamic outline with a mass distribution which ensures the rotor operate with minimal vibration and very low noise;

● Perfectly matched rotor and generator cause much less resonance of wind turbine and tower;

● Blade aerodynamics braking limits blade to rotate at rated RPM which could avoid higher noise and vibration caused by extreme wind.

4 - Specifications

Model HY-1000L/24V

Rated Output 1000W

Peak Output 1200W

Rated Voltage(V) Off-grid DC24V

Start-up Speed 2 m/s or 4.5mph

Cut-in Speed 2.5m/s or 5.6mph

Rated Wind speed 12m/s or 26.8mph

System average Cp.

>0.36

Rate Charging Current (A) DC41.7/20.8

Noise level <30dB (@50 feet distance from hub center)

KWH/month (monthly avg.

V 5.5m) Approx.

175

Working Temp.

range from -40°C to 60°C

Survival Max.

wind 50m/s or 110mph

Overspeed control Electromagnetic brake & blade aerodynamic speed control

Number of Blades 5

Rotor Diameter(m) 196

Swept Area (m2) 3

Blade Material Strengthened nylon glass-fiber

Generator Type Brush-less 3-phase PMA with high performance Neodymium Magnets

Tower-top Weight 28kg

Tower Type self-supporting, guyed, Tilt-up tower or rooftop mounting etc.

Controller Type MPPT or PWM

Applications solar & wind hybrid lighting, on/off-grid power system etc.

Product Life (years) 15

Warranty (years) 3 years

Years on Market 5

Unit Sold Worldwide >12, 000 sets

Certificate Certified by ISO9001: 2000, CE, RoHS, ETL
