ONWA®

5.7 TFT LCD GPS CHART PLOTTER

MODEL: KP-6299

FEATURE:

1 - High resolution 5.7 inches day-view LCD display

2 - SD-cards slot for C-map Max and user data

3 - C-map Max and K-chart Selectable

4 - Tide table

5 - Versatile display modes including:

- Plotter Screen

- Nav Data

- Satellite Information

- AIS Display

- Compass Screen

6 - GOTO Track Navigation

7 - Map Orientation Select

8 - Proximity waypoint alarms

9 - Perspective View

10 - Palette

- Normal

- Daylight - Exposed to Sunlight

- Night - In Dark Environment

- NOAA - Paper Chart Colors

SPECIFICATIONS

Plotter Characteristics

1 - Waypoints/Icons: 15, 000 waypoints with name, symbol, 10 proximity waypoint.

2 - Route Memory: waypoint up to 200 points each, plus MOB and Track Navigator or Goto track modes

3 - Alarm: XTE, Anchor Drag, Arrival, Speed, Voltage, Proximity, Waypoint and Time, AIS alarm.

4 - PALLETE

- Normal

- Daylight: Exposed to sunlight

- Night: In dark environment

- NOAA: Paper chart color

5 - Tides: Tide Data

6 - Projection: Mercator projection

7 - Position format: Lat/Lon

8 - Base Map: Built-in ONWA K-Chart

9 - External Map: SD cards slot for user settings

10 - User data storage: Internal backup of user settings, or external SD-card

11 - Plot Interval: 1s to 99h or 0.01nm to 9.99nm

12 - 0.01nm to 1, 000nm

13 - Nav Data Input/Output:

- Input:

$-DBT, $-DPT, $-GGA, $-GLL, $-MTW, $-RMA, $-RMB, $-RMC, $-VHW, $-VTG, $-ZDA

- Output:

$-AAM, $-APB, $-BOD, $-BWC, $-GGA, $-GLL, $-RMB, $-RMC, $-VTG, $-XTE, $-ZDA, $-

WPL, $-HDG

- Output for autopilot:

$-AAM, $-APB, $-BOD, $-VTG

14 - PERSPECTIVE VIEW: On/off

GPS Receiver Characteristics

1 - Receiver: 12 parallel channel GPS receiver continuously Tracks and uses up to 12 satellites to compute

and update your position

2 - Acquisition: Cold start: 60 seconds average

Warm start: 45 seconds average

Hot start: 15 seconds average

3 - Update rate: 1/second, continuous

4 - Accuracy: Position: <15 meters(95%) without S/A

Velocity: 0.1 meter/sec without S/A

Time: ±100ns synchronized to GPS time

5 - Dynamics: Altitude: 18, 000m Max

Velocity: 500 m/s

Acceleration: 4g Max

6 - Datum: WGS 84 & Others

7 - Interface: NMEA 0183 Input and Output, RS232 and RS422 output

8 - Antenna: KA07
