Electronic Ballast Compatible Led Tube - China

Features:

• Direct Retrofit for conventional T8 fluorescent tubes with Electronics Ballast.

• 2835 SMD LEDs with high luminous efficiency.

• Quick, simple and safe replacement without rewiring.

• T8 size shape with G13 socket.

• Optimum light uniformity and high color homogeneity.

• Extremely robust with aluminum heat sink and polycarbonate cover.

• Power Factor: 0.95 -

• Overpower, short and open circuit protected.

• NO noise, NO flicker, NO UV and IR.

• Mercury-free and RoHS compliant.

• Comply with CE, FCC and UL standards.

Technical Specifications:

Physical Specifications

Length: 600mm 1200mm 1500mm

Weight: 212g 360g 441g

Housing: Aluminum Base+PC Cover

Lens: Milky/Clear

Tube Diameter: T8

Base Type : G13/R17d

Work Environment: Indoor use (applicable for dry environment)

Electrical Specifications

LED Quantity: 72LEDs 120LEDs 152LEDs

Power Consumption: 10±1W 18±1W 22±1W

Output Current: 250mA 430mA 530mA

Input Voltage: 85-265VAC

Power Factor: >0.95

Light Source: 2835 SMD LEDs, more than 21LM each

Operation Temperature: -20~40 °C

Optical Specifications

Length: 600mm 1200mm 1500mm

Power Consumption: 10W 18W 22W

Lumens:

For clear : 910±10%lm 1800±10%lm 2310±10%lm

For milky : 850±10%lm 1690±10%lm 2160±10%lm

Luminous Efficiency:

For clear : 91lm/w 100lm/w 105lm/w

For milky : 89lm/w 94lm/w 98lm/w

Color Temperature:

Warm White: 2800K-3200K

Natural White: 4000K-4500K

Cool White: 6000K-6500K

CRI: >80

Beam Angle: 120 Degree
