Single Crystal Silicon Prime Test Wafer 2 Inch 3 Inch 4 Inch 5 Inch 6 Inch 8 Inch At Western Minmeta - China
price: 1.00 Dollar US$
Diameter: 2" 3" 4" 5” 6” 8"
Conductivity Type: N type or P type
Crystal Orientation: <100>, <111>, <110>+/-0.5degree
Resistivity: 2.0-4.0 Ohm.
cm, 4.0-7.0 Ohm.
cm, 7.5-12.5 Ohm.
cm
RRV: 12% max
Thickness: 350+/-15um, 420+/-20um, 525+/-20um
Primary Flat Length: as required
Secondary Flat Length: as required
TTV: 15um max, TIR: 10um max, Bow: 40um max, Warp: 40um max
Packing: in foam box or cassette, carton box outside
Application: widely used for integrated circuit, epitaxial wafer substrate, LED, transistors, discrete components etc.
As-cut, lapped/etched and polished wafers are available.
Company Contact:
- Posted By: Western Minmetal (SC) Corporation
- Phone: 862885187252
- Address: E2-1-1011, Global Center, No.1700 Tianfu Avenue No, Chengdu , China
- Email:
- Website: http://www.matltech.com
Published date: December 24, 2017
- Business Description: Western Minmetals(SC) Corporation was founded in Chengdu.
We are an
important supplier of refractory material such as tungsten, molybdenum
and mica to the advanced industry.
We are a leading supplier of high purity materials for use in semiconductor compounds, imaging equipment and information industry.
We are a major supplier of mono crystal silicon, cadmium telluride thin film cell material and semiconductor compounds for solar photovoltaic, integrated circuits and other electronic industry.
We are an indispensable supplier of specialty chemicals and inorganic oxide materials to special metals and chemicals field.
