Ingke Ykju 8199nl 100 Percent Cross Arjc01 111002l Rj45 Jacks With Magnetics - China

Ingke YKJU-8199NL 100% cross ARJC01-111002L RJ45 Jacks With Magnetics Part Number : ARJC01-111002L

Made in China: YKJU-8199NL Original Manufacturer: Ingke Technology

Supply Ability: 5500K-PCS/Month

Product Category: Modular Connectors / Ethernet Connectors

Packaging : Tray

Connector Type: RJ45

Number of Ports : 1

Number of Rows : 1

Applications : 10/100 Base-T

Mounting Type : Through Hole

Orientation: 90° Angle (Right)

Termination : Solder

LED Color: Yellow - Green

Number of Cores per Jack : 5

Shielding : Shielded, EMI Finger

Features: Board Lock

Tab Direction : Up

Contact Material : Phosphor Bronze

Contact Finish : Gold

Operating Temperature : -40℃～85℃

Flammability Rating: UL 94 V-0

Contact Finish Thickness : 30µin (0.76µm)

Shield Material : Copper Alloy

Housing Material : Thermoplastic Manufacturer: Ingke Technology Co., Ltd

INGKE can provide 3D model for engineers' design

Our service: 1).

Free sample is available! 2).

OEM & ODM orders are welcomed.

3).

We offer after-sale service for 8 years.

Our Advantage: 1).

High-quality, OEM factory for RJ45 Connector more than 10 years.

2).

Cost reduction, lead time within 1 week, FREE samples.

3) .

After sales services 24*7 to help you solve any kind of problems Ingke Technology Mass production of the following models;

ARJC01-111002AR ARJC01-111002T ARJE-0031 ARJE-0029 ARJ-169 ARJE-0027 ARJ-148 ARJ-196 ARJE-0025 ARJ-139 ARJ-199 ARJ-150B ARJ-205 6605454-1 1840419-2 1840419-3 5-6605758-8 1840419-4 5-6605706-1 5-6605761-1 5-1840406-8 ARJ-202B ARJ-202C ARJ-202 1368589-5 1-6605832-1 ARJ-150A ARJ-150C 2-1840408-6 JT3-1105HL 0845-2D1T-E4 5-6605809-7

Company Contact:

• Posted By: Ingke Technology Co.,Ltd

• Phone: 86 (755) 3283-5625

• Address: No.2106,Sanhe Building,Longgang Zone, Shenzhen , Guangdong , China

• Email:

• Website: http://ingketech.net

• Business Description: Ingke Technology specializes in producing 10/100/1000/2.5G/5G/10G Base-T Integrated RJ45 Jacks, since its establishment1993, with technology as dependence and the market as direction, we have developed to be a competitive high-tech enterprise and a leading manufacturer of connectors.

  Partnered with the global leaders in these markets, we continue to develop new products to enable high-speed communication.

  Now we have passed the ISO14001 Environment Management System certification and our parts are all ROHS, CE, UL and SGS parts.

  Our products are widely used in telecommunications, data communications, consumer electronic , computer, industrialand medical markets, such as HUB, SWITCH, IP Phone, Set-Top Box, Smart Home, Embedded System, Networking Camera etc.
