Ingke Ykjd 8059nl 100 Percent Cross J0026d21bnl Single Port Magnetic Rj45 Connectors - China

Part Number : J0026D21BNL

Made in China: YKJD-8059NL

Original Manufacturer: Ingke Technology

Supply Ability: 5500K-PCS/Month

Product Category: Modular Connectors / Ethernet Connectors

Packaging : Tray

Connector Type: RJ45

Number of Ports : 1

Number of Rows : 1

Applications : 10/100 Base-TX

Mounting Type : Through Hole

Orientation: 90° Angle (Right)

Termination : Solder

LED Color: Green - Yellow

Number of Cores per Jack : 5

Shielding : Shielded, EMI Finger

Features: Board Guide

Tab Direction : Down

Contact Material : Phosphor Bronze

Contact Finish : Gold

Operating Temperature : -40℃~85℃

Flammability Rating: UL 94 V-0

Contact Finish Thickness : 15µin (0.38µm)

Shield Material : Copper Alloy

Housing Material : Thermoplastic Ingke Technology Mass production of the following models;

JGL-0001NL JT4-1109HL JX80-0019NL JC0-1012NL JTH-0020NL J8064D649PNL JC0-1011NL J8064E64NL J1N-0012NL J1N-0013NL JGL-0004NL JX80-0022NL

J1N-0011NL JXG0-0129NL JX20-0037NL J8064E66NL J1N-0006NL J8064D668ANL J0N-0011NL JX8064D668ANL JC0-0351NL J1N-0005NL J1N-0007NL J0N-0012NL J8064E68NL J1N-0004NL J1N-0008NL J0N-0015NL J1N-0003NL JXG0-0098NL J8064D688ANL J0B-0384NL JX20-0114NL JX8064D688ANL J20-0114NL JG0-0070NL JG0-0028NL J0C-0003NLT J00-0045NL J00-0014NL J0011D21NL J3011G21DNLT J0006D21BNL J3026G01DNLT J1011F01PNL J1012F21CNL J1011F21PNL
